1、One casing matches two Impellers design

With different specifications of hydraulic, except for impeller and casing ring, other parts canbe used, reduce the number of spare parts

2、Axially split pump casing

Simplifies rotor balancing, inspection and installation, case passageway inspection andmodification, and spare rotor retrofitsSupport is near centerline for alignmentThe inlet and outlet flanges have the same pressure grade, full range of design pressures tosuit applications

3、The rotor axial force balance design

The impeller is arranged symmetrically and the axial force is automatically balanced withoutthe need for complex balancing mechanismDouble volute structure, minimum radial thrust for less shaft deflection and less bearing loading

4、Multiple bearing types

Ball radial and 7300 series ball thrust bearings are standardPressure lubricated sleeve/pivot shoe bearing are optionalBearing isolators are standard

5、Double suction impeller

Large size pump adopts impeller is double suction structure, the pump has excellent Netpositive suction head required(NPSHR)

6、Axially split bushing and casing ring

Facilitates rotor dynamic balance, inspection removal and replacement

7、Material Options

API610 Material codes: S-5 S-6 S-8 C-6 A-7 A-8 D-1 D-2
