1、Fange

The standard is ANSI B16.5 150 lb/300 tb, and other flange standards can also be implementedaccording to user needs.

2、Pump casing

Self -exhaust design, center line outlet. Outlet greater than 80mm double volute design,effective balance radialforce.

3、Impeller

NPSH3/ CFD designed for enhanced efficiency and NPSH3.

Balance hole, effectively balance the axial force, increase the service life of seals and bearings.

4、Bearing

Back-to-back mounted ball bearings and cylindrical roller bearings are used together toeffectively balance radial force and residualaxialforce

5、Full cartridge mechanicalseal

Ease of sealreplacement and assured accurate seal setting

6、Classically stiff shaft design

Deflection at mechanical seal less than API 610 limit for longer seal life.

7、Material options

API610 Material codes: S-5 S-6 S-8 C-6 A-7 A-8 D-1 D-2
