1、Pressure casings

The barrel and suction, discharge pressure regionsare the equalpressure rating which are designedfor MAWP, there are two ratings CL300 or CL600.

2、Hydraulic components

Diffuser or blower inlet casingUnless otherwise specified and approved, Stan darddesign without inducer.

3、Axial force and radialforce balance design

Precise balance calculation. The axial force can becontrolled, pump running stability.Multistream diffuser or blower inlet casing design,balance the hydraulicradial force of the rotor

4、Bearing

A pair of angular contact ball bearings.an for standard configuration, Air cooling and water cooling can be selected when pumpedhigh-temperature liquid.

5、Shaft

Standard shaft is a whole, not segmented. Longer shafts need be connected with two ormore shafts when necessary.

6、MATERIAL OPTIONS

API610 Material codes: S-5 S-6 S-8 C-6 A-7 A-8 D-1 D-2
